APPLICATIONS:
Glanding For watertight glanding of unscreened circular cables.
PRODUCT FEATURES:
- Halogen free
- Silicone free
- Phosphorous free
- Cadmium free
- Self extinguishing
CONSTRUCTION:
Material Bright nickel plated extruded brass gland body and compression head (Brass BS EN 50262 1999 / Brass extrusion BS 2874 CZ121 3Pb).
Seal PCP (Neoprene) rubber.
O-Ring PCP (Neoprene) rubber.
Insert Polyamide 6 traction relief clamping insert.
CHARACTERISTICS:
Operating Temperature Range -40°C to 80°C. Up to 100°C for short periods.
Protection Class Water rating IP68. Pressure rating 5 bar.
